Semi-automatic aluminum foil rewinding machine



ATW-SD600

Semi-Automatic aluminum foil rewinder

(For Aluminium foil) (uploading paper tube and glueing by hand)(it is suitable for making long meters from 30-300m)



Specification :

Material thickness: 0.009-0.02mm

Maximum Unwinding Width: 500mm

Maximum Unwinding Diameter: 600mm

Rewinding Width: 100-500mm

Mother Core Diameter: 76mm/152mm (option)

Finished Product Core Diameter: 25mm/30mm/35mm (option)

Length of production: 30m-400m

Production Speed : 0-300m/min

Power of Motor: 2.2 kw

Machine Weight: 1200 kg

Machine Dimension (LxWxH): 1100x1350x1500mm

-Specification :

Material thickness: 0.009-0.02mm

Maximum Unwinding Width: 500mm

Maximum Unwinding Diameter: 600mm

Rewinding Width: 100-500mm

Mother Core Diameter: 76mm/152mm (option)

Finished Product Core Diameter: 25mm/30mm/35mm (option)

Length of production: 30m-400m

Production Speed : 0-300m/min

Power of Motor: 2.2 kw

Machine Weight: 1200 kg

Machine Dimension (LxWxH): 1100x1350x1500mm
