Shrinkable film packing machine

Shrink film packing machine



Components:

1. Auto Feeder

2. UV sterilization light

3 Auto paper tube glueing

4.Auto paper tube uploading

5.final foil roll collecting belt

6.Siemens PLC



Specification :
1.Thickness of raw material:              -0.01mm0.02mm

2.Width of raw material:                  -100-500mm

3.Maximum unwinding diameter:           -600mm

4.Inner diameter of parent roll core:        -75mm

5.Inner diameter of finished product roll core:- 25 ,30 ,35mm

6.Finished roll length:                    -3m--300m

7.Production efficiency based on length of roll.

8.Unloading magnetic powder brake:       -25N.M

9.Winding magnetic powder clutch:        -12N.M

10.Overall dimension:                    -4000*1350*1710mm

11.Rated power of complete machine:      -4KW

12.Compressed air pressure:             -0.5 Mpa

(prepared by the customer)

13.Weight of complete machine:           -1500KG



Character:
Kitchen foil roll, PP film roll and others rolls could be shrink wrapped by this ideal machine.

Specification
Main Technical data:
Film Material Width: -150-450mm
Product Roll Diameter: -25-60mm-
Speed: -0-25roll/min
Voltage: -380V/220V (50Hz)
Machine Power: -6.75Kw
Machine Weight: -1100kg
Dimension (LxWxH):-3520x1350x1350mm
